Type XXI U-Boats (1944)
Nazi Germany, 1,170 planned, 118 completed (1944)
The Elektroboot saga: Too late to win
The Type XXI were large scale production Kriegsmarine’s “wunderwaffe” planned by Nazi Germany at the end of the war. Alongside the smaller Type XXIII “Elektobote” and numerous “midgets” at a stage events verged on desperation, it was suppose to reverse their course. Announced as the boldest leap into the future for the Kriegsmarine so far, the world’s most advanced submarine design of their time, The Type XXI would be also a powerful inspiration for all navies in the next decades, and up to the 1957 USS Nautilus. But was it a real game changer in 1945, or just an overblown propaganda effort ? Here’s the detailed answer.
A technological revolution: From submersible to submarine
With the Type XXI, for the first time, Germny made a decisive step from a “submersible” to a “submarine”: The philosophy that prevailed since 1905 was that a “submersible” was essentially a torpedo boat that submerge at times, for all emergency. Such vessel cruise at the surface most of the time, running on sobre diesel engines, and went underwater on electric power generally to escape an attack.
Due to the limitations of electrical power at the time and having no accurate system to detect targets from underwater, a submersible was essentially slowed to a crawl, deaf and blind, limited in diving to it’s own lenght deep. Renewing the air or expelling surplus acid gases generated by the use of batteries caused “broths” detected for miles around the surface by planes on patrol, while the slightest noise on board betrayed their presence to more and more sophisticated hydrophones, not to mention their radar signature when surfaced.
This base principle stayed the same for all submersible models built by all nations from WWI to WW2. The so-called (improperly) “battle of the Atlantic” was led by U-Boats, essentially the same models as the WWI mass-produced (92 on 129 planned) Type UB III, notable ancestors of the WW2 Type VII (1936), a single, simple mid-range model, mass-produced until 1945. Although the latter was improved in many ways, limitations were stil present.
The conclusion of all reports for losses to the allies were plural in origin: More escorts, more ships to sink (Libery/Victory), better tactics, better detection system, better armament, constant naval aviation patrol, and unbeknownst to the German naval staff, full knowledge of impending attacks thanks to the breaking of the Enigma machine by the Turing computer at Blechley Park.
The 1943-44 “Wunderwaffen” craze
This traduced from mid-1943 onwards, to a growing, and soon unsustainable number of losses. It reached such a point in early 1944 that Grand Admiral Dönitz, now at the head of the Kriegsmarine since January, considered the battle as nearly lost. There were solutions though: Out-producing the allies was out of question, due to internal resources strained to the limits: But the credo at the time, by mid-1943, was to win the war by technological superiority: German quality versus allied quantity.
Many “Wunderwaffe” projects, some dated back from before the war were looked upon again. For the Luftwaffe, it was a rush towards jets which culminated with the Me-262. For the Heer, tanks such as the Königstiger. For the Kriegsmarine, the “poor child” of German arms as always, it was the Walter boats. Dönitz became passionated about the project.
Albert Speer’s reorganization of the production meanwhile allowed a move towards inscreased production of existing U-Boats, which was simplified, modularized and atomized between a constellation of sub-contractors working in relative security, to mitigate the effect of allied bombardment.
As a result, U-Boat production was maintained despite all odds. Choices were made, like axing of the large and costly oceanic Type XB and minelayers or specialized types gradually cancelled to concentrate on the late versions of the excellent Type VII alone.
But the Type VII still had its load of limitations, the ones described above. One innovation though, the Snorkel, was very promising and started to be adopted, as well as radars and a more effective FLAK, or better torpedoes. But since 1941 already, the research bureau of the Kriegsmarine was looking for a more radical approach, destined to completely change speed underwater, and giving the submersible an almost unlimited underwater range.
No technology at the time could provide a direct answer, but one man at least had a solution, leaning towards a modern “AIP” (“Air Independent Propulsion”). From these efforts, the initial program leading to the Type XXI can be traced back. This was Helmuth Walter’s turbine, the awaited game changer. For more, see also the U-Boat Types.
Towards the pure submarine: The Walter Propulsion
About Professor Walter
Professor Walter had patented a motor fuel system that uses nitrogen peroxide, a very unstable product that had the advantage of allowing these engines to remain completely autonomous, with little or no vibration, and above all to stay in operation. It allowed diving almost indefinitely, at high speed. This revolutionary process quickly interested the Nazis, who commissioned a first project in 1933.
However the rearmament priorities lowered this program, and it was postponed. It was not until 1939 that the first “Walter Propulsion” submarine was built. The V80, displacing 75 tons, for 22 meters long, thanks to its refined hull shape, easily reaching 28 knots submerged. This was an absolute record at the time, only beaten with the 1960s SSNs of the cold war. The following V300 in 1942 inaugurated a high-pressure turbine. She started as the first operational submarine in 1943, the U-791, giving birth to the U-792 and 793, 794 and 795, armed with forward torpedoes, which went through month of gruelling operational service (see below). But even with the emergency, the Kriegsmarine was dubious, cautious with this new technology.
Walter’s U-Boats
Various Walter Boats: V.80, Type XVIIA and XVIIB
The experimental propulsion that Professor Helmuth Walter advocated since 1931 was worth trying. A brilliant engineer her worked on a new gas turbine at the Germaniawerft shipyard (Kiel) from 1933, closed circuit propulsion system. Intended for submarines obviously, he proposed to replace ultimately both the electrical batteries and diesels by a new powerplant driven by hydrogen peroxide (H2O2) in a stabilized form, called Perhydrol.
This was a complex combustion process, but it helped creating a smaller, lighter engine with far less parts, occupying a small internal fraction of a normal U-boat, freeing space for whatever could be useful, like extra torpedoes. It was to stay for much longer underwater, not having to surface to recharge batteries and safely travel to its attack position. At the time, the Type VII did not even existed, but it was believed to be adapted on any U-Boat type in the works.
In October 1934, he proposed to the OKM (Oberkommand des Kriegsmarine) a special type of 300 tonnes U-boat, based on the Type IIA hull, but with a top speed of 26 knots and underwater speed of 30 knots, which was unheard of at the time: The average was around 7 knots. Endurance was also greater than the original, reaching 2,500 miles at 15 knots (500 miles submerged at that speed also). This “high speed U-Boat” however seemed far fetched, or had no practically use for the kind of submarine warfare thought at the time in Germany, just starting a gradual rebuilding of its submarine force, step by step.
Walter’s proposal was rejected as too unconventional, even deemed fanciful. Walter however never gave up. In 1937 he managed to show his revised plans to Karl Dönitz, at the time at the head of the small U-boat training flotilla. Dönitz was impressed enough to push for this project into the administrative echelons, through the top of the OKM, resulting at last in 1939 to a design contract. With war looming the proposal seemed interesting enough to fund a small research submersibles called V-80. But production out of the question.
V-80 was designed under supervision of Walter at Germaniawerft, Kiel, built under the greatest secrecy, on a slipway surrounded by a large fence. Launched on April 14, 1940 it was fitted out relatively quickly and started a serie of tests, at first in port, then at sea, and made a serie of dives. Test results, released in the spring 1940, with Walter himself at the controls, were brillant. As predicted, his turbine managed to propel his submersible to an amazing top speed of 23 knots submerged. This was a world record, quadruple of any model at the time.
It would wait second generation nuclear-powered attack submarines to reach that speed limit, such as the Soviet Alfa class (42 knots), so forty years later. Surface speed was also excellent, far better than any U-Boat in service so far. The turbines seemed also reliable at first, and although no max autonomy test was performed for safety, Walter was confident, the predicted range would be achieved.
The report, pushed by Dönitz into the OKM, made a sensation. The OKM upon this, suggested immediate construction of six coastal U-boats, based the V-80 design. Still, there was plenty of resistance in the U-boat department. They asked about how a real operational boat would perform, in proper combat conditions for such an untested solution. There were doubts also on how to manage a new logistical chain to hold the compounds involved in the combustion, and there was little room available in already hard-pressed shipyards to deliver the VII and IX U-boats, which seemed at the time more than sufficient for their task. In 1941 indeed, the results obtained by the early Wolfpack tactics were very encouraging. It was a war-winning strategy, dark days for the allies. Soon in early 1942, the “happy times” would commence for the U-boat arm.
Eventually, the OKM heard about these remarks and reworked the project to create a compromised design: The 600-ton V-300 (Later unique Type XVII, individually “U-791”). The goal was to produce a realistic militay model which can achieved 19 knots submerged. Construction started at Germaniawerft, but cancelled when Walter saw the design and told the OKM he could on the same basis obtain a much faster, 220 tons boat.
The semi-experimental Type XVII
A meeting with Dönitz in January 1942 had new contracts drafted, and awarded for 4 boats, all at Germaniawerft, Kiel, the Wk202 “serie” (U-792 and U-793) and in Blohm & Voss in Hamburg the Wa201 serie (U-794 and U-795), representing the Type XVIIA. Both series had the same dimensions but diverged in their shape and kiosk’s shape ad other details. They were armed with just two standard 21-in torpedo tubes for proper military evaluation. Keels were laid down eventually in December 1942 in both yards, with U-792 launched on 28 September 1943, followed by U-794, on 7 October 1943. Apart testing their powerplant, their goal was to training intensively to mimick combat conditions. As planned they reached 25 knots in 1944. In March 1944 U-794 performed a 24 knots run in in the Bay of Danzig, assisted by Dönitz and four other admirals.
In 1944 also were started boats of the Type XVIIB, now a full serie. U-1405 to U-1416 were to be built in Blohm & Voss, Hamburg. They were longer, and had the same Walter gas turbine rated for 2,500 PS (2,500 shp; 1,800 kW), doubled by a single Deutz SAA SM517 supercharged 8-cylinder Diesel engine, 210 PS (210 shp; 150 kW) for the surface, at 9 knots (17 km/h; 10 mph), an AEG Maschine AWT98 electric motor, 77 PS (76 shp; 57 kW) allowing 5 knots (9.3 km/h; 5.8 mph) submerged on electric drive alone, and 25 knots (46 km/h; 29 mph) submerged (with the HTP Turbine drive). They carried the same two bow 53.3 cm (21 in) torpedo tubes with two ready and two torpedoes in reserve. But these were only coastal models, at 312 t (307 long tons) surfaced, 337 t (332 long tons) submerged and 415 t (408 long tons) total, reaching 3,000 nmi (5,600 km; 3,500 mi) at 8 knots (15 km/h; 9.2 mph) surfaced. Only the first three were operational for a short while, scuttled in May 1945. The remainder, U-1408-U-1410 were incomplete when the war ended and the U-1411-U-1416 saw their contract cancelled. A dedicated article will cover them in the future.
Well before this, back in 1942, Walter proposed this time a large military U-Boat, of some 1,475 tons standard, to be called Type XVIII. It could carry 23 torpedoes, for four bow tubes. Two contracts were awarded, on Jan 4, 1943, to Deutsche Werke, Kiel for U-796 and U-797, and then cancelled on 28 March 1944. In between, discussions betwen the OKM and Dönitz prioritized the XXI. This was simpler, cheaper “spin-off” of the Walter design, with a massive battery capacity, and not the Walter turbine. By this trick, the Type XXI was still able to reach 17 knots submerged.
Indeed, in between, tests performed by Kriegsmarine crews in near-combat operation in 1943 went to the OKM, and were less stellar about their performances: The complexity of three powerplants, and the turbine itself, was really above the average level of training asked from Kriegsmarine rating at the time, maintenance was complex and costly, totally captive of a very uncertain supply of Perhydrol, for which no solid supply has been planned yet. Also, it was found the fuel was highly flammable. In fact, the Royal Navy also had engineers working on such concept, and eventually abandoned it as too dangerous for combat.
The legacy of the Walter boats was not lost however. It did not went into cold-war models, which rather derived from the more conventional Type XXI, but found their way in concept, in modern AIP systems used for conventional “diesel-sub” atack submarines. Technology made giant leaps to procure a safer system and reach even greater speeds and autonomy. But it took more than 70 years to reach this level. Prof. Walter did not lived long enough to see his vision realized, when he passed away in 1980. Germany indeed embraced only in the 2000s the concept of fuel cells, now propelling the Type 212, 214, 218 and modified 208-1400.
The clock is ticking: Inevitable Compromises
Not only this research progressed very slowly, but the limitations seen above were considered too much for the Kriegsmarine organization and for combat conditions. Priority was given to a simpler model eventually: The type XXI, marrying the new hydrodynamic hull resulting from the advanced researches in this field (with large models in test pools), but a more conventional, trusted diesel, and incorporating a massive provision of batteries, which allowed a final 17 knots or 220 miles at 9 kts submerged, which was enough to “disrupt” allied ASW warfare, combined with the advantage of the snorkel, to make the subs “stealthier”.
It was not the powerplant hich eally set apart the Type XXI from all other submersibles of the time, but the whole “package”: Anti-vibration system to separate the powerplant, making it more silent at low speed, when diving, magnetic jammers against Deep-Charges, the snorkel allowing to stay indefinitely submerged but at constant depth, or an oil/air releasing system to confuse observers (believing a successful grenade attack was made), the new high-speed automated torpedo launch system, the latest magnetic homing torpedoes.
Externally it went as well with a completely new hull and sail shapes, result of years of refinements, calculation and tests, or the new semi-automated anti-aircraft system with remotelly operated electric turrets, a new listening system, more powerful and accurate for underwater detection. And the crew’s comfort was immensely improved because of more automation plus more internal space (with a smaller crew !) better facilities, freezer for food, more sanitation spaces, proper showers and even a bathub.
Development of the Type XXI
Overview and internals, original blueprints reconstructed by the Bundesmarine.
Paying a staggering price
To get from the 1930s Type VII and IX to this “spaceship” was not a smooth ride, though. The first trigger was of course the degrading situation in the so-called “battle of the Atlantic”: First signs of this came in July 1942 – February 1943 when losses rose steadily. The better organized US Navy for convoy escort, and massive output of shipyards on both sides of the pond, which indeed had a massive impact in the matter. But what really turned the tables was the famous “black may”, or March–May 1943 which saw increase ferocity on both sides, and only 39 ships (235,000 tons) were sunk for 15 U-boats destroyed.
Later in May, in a single convoy, 30 U-boats attacked, but only managing to sink 13 merchant ships, for the loss of six U-boats. This was one U-Boat traded for two merchant vessels. Already an unnacceptable price to pay compared to the 1941-42 ratios. All in all this month alone, 43 U-boats were destroyed, 25% of German U-boat Arm’s at the time. At this rate, seemingly increasing, the whole “battle of the Atlantic” would be lost within six months, unless drastic changes took place.
Since Dönitz was at the head of the Kriegsmarine from January, submarine warfare was given all priority and major surface assets were transferred to Norway to operate aainst the Murmansk Convoys and tie down a substantial part of the Allies in effort escort. Submarine construction had all priority and resources, manpower available and it went to the existing Type VII and Type IX as well as a few Type XIV for refuelling. The 1943 Fleet Building Programme notably had Dönitz peesuading Speed on the provision 40 U-Boats per month being completed, despite a growing lack of steel, in high demand notably for the Heer.
On late November 1942, the OKM send three naval builders to Paris for a meeting with Dönitz. Dönitz then started to number the losses: In 1940, twenty four, 1941 thirty three, 1942 a bit less for the first half, but it has been steadily rising since then as in July 1942, nine were lost, in August twelve, in September nine in October fourteen as for November, 80% of those in the surface. The core problems that he had submersibles, not true submarines. Statistics were clear about this: His U-Boots needed to stay underwater longer. He also gave his hopes for the the construction of the new Walter submarines, and the Type XXVIII the largest of these. But he also expressed his concerns about this untested tech and delays, the great industrial risks it represented.
One of the yard, eager to get an order fast, proposed to just streamlining the hull and doubling the electrical ppiwer, or even quadrupling it, while building a much larger submarine, preserving its surface qualities, notably in rough weather. Dönitz expressed doubts about the fact hos boats needed to surface often anyway, and he was told about a new “all-weather” Schnorchel model. Another expressed their idea about a semi-automated reload system for torpedoes.
Dönite became very interested and to conclude, asked for when this alternative type could be ready, and he was answered spring 1943. This was the birth of the Type XXI.
When the first designs were presented in June 1943, as imperfect and rough as they were, Dönitz’s fears came true as the previous “Black May”, losses has been crippling. Now was not the time for tedious half-measures. A new submarine was needed fast. Development of the new Type XXI from there, now officially named, was given all priority and the Walter boats fell into low priority; In the end, three times more batteries were planned, an armoured bridge and new streamlined hull were all in the works.
The new electrical power allowed, combined to the streamlining, to make seventeen knots underwater, but it still only existed on paper. Now the same builders that met in Paris by November 1942 assured Dönitz that the first boat would be ready… in late 1944. Dönitz by now had to make a very difficult decision to either give up submarine warfare entirely, or held his breath, took measures to spare his crews, and gamble on the new type, provided there was a way to have it faster.
Depite the losses, keeping the crews at sea, was the only way to have his men staying sharp, and even they did little damage at this point of the war, this ASW campaign still tied down countless allied ressources for convoy escort alone. Plus he would have experienced crews to make the transition towards the new type. Meanwhile, both the Type VII and IX still filled the order books of the three yards in charge of submarine production in Germany. They will deliver both types up to the last day of the war, but at a lower rate.
The year in between, from mid-1943 to mid-1944, Dönitz also frantically worked to improve the tech of his actual Type VII/IX. Until late 1944 they were continually improved. Better engines, better range, deeper dive, a schnorchel, new radars, and plenty of anti-aircraft guns. Kapitänleutnant Hartmann was the first to sail the new anti-aircraft submarine type, but even through, he was attacked by several British fighter-bombers and severely damaged, with all hi men on deck killed, himself and his staff. She was back to port commanded by …the medic on board, sole officer left. Reserve-officers got on board and a few days afterwards, she was at sea again.
Meanwhile, German shipyards were geared up to new forms of production setup for the Type XXI. Albert Speer, Hitler’s secret weapon for Germany’s production, was the minister responsible for this programme, promising deliveries in May 1944, well befoe anticipated. And he kept his promises (see later).
Production planning of the Type XXI
The while the year 1943, and early 1944, were fought with the same types, it’s only in the spring of 1944 that the Type XXI submarine was scheduled to reach frontline. Back in July 1943, the The Central Shipbuilding Committee and the new building programme knew that plans for the new Type XXI were not ready, the Walter turbines was now appearing not suitable for operations, and the “backup solution” was ready, although many technological issues were still at hand. So development was given time: The comittee envisaged the completion of the first two of them, as serie protoype in November 1944 and the pre-production prototype in December 1944, with trials in the spring of 1945. The plan also comprised a production of 30 boats a month by the autumn of 1945.
In addition, this programme presupposed that Speer was prepared to provide all requisite building facilities and work would proceed without interference by air raids or bottlenecks, which Dönitz found unrealistic. Soon the increasing number of air raids and destruction of Hamburg gave him credit. While he asked Speer to submit counterproposals, the latter granted the first Type XXI completed in Apri 1944, which left hope production would start sooner.
Both men eventually struck an agreement over which the new type was accorded all priority freezing any alternative naval construction, and they they would benefit for prefabricated, mass-production principles, possibly in well protected, bunkerized final facilities in which the various final modules would be assembled. If it’s looking very modern to us, it was at least groundbreaking for major naval construction. After all, the Type XXI were planned to be much larger even than the Type IX.
Instructions planning for the new U-Boat models started at the Construction Office in Glückauf, Blankenburg. The Autumn of 1943 saw first orders placed with contractors involved already to provide U-boat electric batteries, as well as those for the pressure-hull sections and a galaxy of sub-contractors. On 8 December 1943, constructional drawings were at least completed. On 1st January 1944, the new programme was submitted for approval, targeting the completion of a prototype in April 1944 as agreed by Speer, with another date of 30 boats completed by July 1944. There same program did not concentrated exclusively on the Type XXI. Considering quantity also had a quality, the first Type XXIII, coastal “Elektroboote” were to be completed in February 1944, plus 19 delivered in April (see later).
Final Design
Inverted negative blueprint of the Type XXI.
General Overview
Colorized sections of the Type XXI- Green: living quarters, blue: central operation, purple: torpedo room, yellow and orange: batteries and accumulators, pink: Electric engines and diesels.
The general outlines of a Type XXI were nothing lile all previous designs, in stark contrast to the Type VII, IX and all the others. This was such a leap forward, early crews coming from older surviving U-Boats or new ones, trained on older models were just astonished to see something out of a Flash Gordon strip, a swatiska-carrying spaceship made for total superiority at sea.
The fruit of months of basin researches, starting for engineered shapes to achieve the least water resistance underwater, the Type XXIs lost their “surface-first” approach, with a relatively conventional hull over waterline level, with a flat deck, and clear separation between the outer hull and pressure hull below, a cylinder and square-section above.
The Type VII blended all these shapes in a single elliptic section all around, blending into the flat deck, which was still there. This was calculated a creating less disruption at high speed underwater. Far before the “droplet style” of more modern SSNs, this was the first attempt to design boats able to reach great underwater speeds, and great care was given to define the best penetration rate possible. Outside the all-rounded sides, the outer hull was not much deeper, but longer overall, creating a greater buoyancy reserve.
Crucially, the bow was no longer “clipper-like” but rounded, a feature universally adopted in cold war years (like for all converted “fleet snorkels”). This rounded bow indeed ctreate les turbulences at great speeds underwater. The forward part was still fine and narrow, sich its cutting edge below the bow curve, facing the three torpdo tubes forward, enclosed in recesses, with each their own shutter, as for previous classes. When closed, the hull was much more streamlined. Above the tube, in the inwards recesses directly below the bow was the larger section of the upper bow. The lower part, below the tubes, was thicker and reinforced to mitigate any impact on the seafloor or obstacle.
Not far below, mid-way of the downward curve, was installed a protruding sonar installation. The ends of the lower bulge was blended with the next belly section. As all previous types, the outer hull was dotted with filling ports all along. The inner pressure hull was about 50% volume compared to the outer, thinner hull. It stopped about 10 meters from the bow, mid-way at the torpedo tubes, and went aft about the same distance from the stern, at the end of the machinery space, which occupied about 1/3 of the total lenght, same for the crew spaces and battle stations in the middle, and the smaller section forward being used for the torpedoes. This space was reduced due to its automation. There was small access hatch for maintenance, but it was no longer crammed with railings, chains and pulleys needed for manual reloading as in previous boats. Nobody slept there either.
The last external changes were of course the absence of a deck gun from the start, and the AA armament in remote turrets fore and aft of the main island, which was itself self-enclosed and streamlined unlike previous “kiosks” opened conning towers with wave breakers and AA platforms. The new island was bulkier, but way cleaner. The central section was also the largest, both in beam and height, with three stages for the first time in any German submarines: The upper one was the main living quarters, with triple bunks for the crews, close to the central, which location did not changed, but this time over three levels, whil the rest of the two lower decks were entirely occupied by batteries, placed at low as possible for gravity. Cumulated with the island that was two-storey high, the Type XXI were the roomier and tallest German submarines ever built.
Modular Construction
The Type XXI sections in details. Note the kiosk, rebuilt postwar: This shows the Bundermarine’s Wilhelm Bauer.
The Type XXI comprised eight separate sections, each being its own sealed compartment, with safety hatches. These ovale sections were constructed in 13 different yards. This allowed on-site duplication and taylorisation with assemblu of sub-elements, often coming from other suppliers. This ensured that if a number of sections were destroyed in one yard, other provided the same sections. Redundancy complicated the chain supply though for each manufacturer.
Safety of this section-building up to the final assembly in the naval yards rose concerns as the most exposed, tipping point of the whole manufacturing chain, and in 1944 efforts were made to provide bomb-proof sheltering. The largest bunkers ever devised in Germany, larger even than the ones designed to protect in France U-Boats (the “u-boat pens”) was exemplified at Hamburg-Finkenwerder and Bremen-Farge, the two prototype buildings to deliver sections. A few others were improvised in less sensitive sites. Due to their size, sections could only be transported by water, whiwh restrained the list of possible sites.
A section-building yard was supplied with similar part-sections for the first section, like thee stern, with delivery of the remaining parts timed to ensure completion in sequence. At any given time, the same number of sections were always in progressive stages of assembly at each yard. Larger part-sections machined and prepared for assembly in the central line, corresponded to smaller ones from machine shops, on a conveyor-belt, creating a tree-like supply, typical of taylorisation. Same operations were repeated on each section by the same skilled team for speed.
The delivery of these completed sections ended in the U-boat assembly yards. There was one in Bremen (Deschimag), another in Hamburg (Blohm & Voss) and a third in Danzig (Schichau). Final assembly consisted in welding the section together, and fitting the last large parts (like the prop shafts), the island, etc. up to the launching under a strict time-table. Difficulties arose in early stages as many issues were discovered and fixed along the way to provide this smoothness.
Section-building yards initially were unable respect their schedule, mostly because of a delayed delivery from subcontractors, especially for the most crucial fittings, which blocked all subsequents steps. Also, the first part-sections sometimes were badly rolled, exceeding their specified tolerances when arriving a the final assembly yard. They often necessitated additional work. In addition, in the rush to keep the schedules, some supposedly complete sections arrived not only late but unfinished, requiring supplies and additional work.
The Central Shipbuilding Committee permitted no shifting in the tight schedule, ruthlessly insisting on their strict observance. This cause launched boats in such as state they needed much work remaining, pushing back for many weeks and even months any completion, and thus, commission. A lot of these finishing tasks were either botches or skimped entirely, which later forced the newly commissioned boats, long periods in dockyard to fix discovered issues. The first seven boats batch was therefore the most laborious of the whole serie, and crews were suspicious of their own safety onboard. The Kriegsmarine after a few trials, kept them for training and experimentations.
The whole program was so challenging, it grew tension and antagonism, even in the Central Shipbuilding Committee itself, but also with the Kriegsmarine Naval Command and dockyard authorities as well. It’s only by the summer of 1944 that there was some noticeable improvements, after weeks or ironing out the whole process and reorganizations. The Shipbuilding Commission under Admiral Topp was instrumental in this, created earlier that year, and acting as mediator and consultant, notably between the Naval Command and Armaments Ministry.
All was done under nerve-wracking reports going from all Germany to the administration of the Armaments Minister, caused mostly by bombing, which destroy assembly sites, the stopped the sub-contractors supply, or, in large final assembly yards often bombed, complete flight of dockyard workmen, notably in Hamburg and Dantzig. In the latter, the collapse of the Estern defence meant the destruction of bridges, pontoons and cranes badly needed to carry the sections. Most often in 1944, work was transferred to other, less exposed factories, and as much as possible, smaller parts were made by slave labor in tunnels, caves and underground.
Despite all odds, unthinkable production rates were meet: 234 U-boats were built in 1944 (220,000 tons), versus 238 in 1942, just as the bombing campaign was ramping up. The highest monthly rate was in December 1944, in which 31 submarines, including 22 of the new Type XXI were delivered. It was just 24 in October 1941 or 23 in November 1942, 28 in December 1943. Despite more and more severe bombins, the average monthly rate in the first quarter of 1945 stayed very high, and the continuous smoothing of the assembly process all along. Nevertheless, by transferring naval construction from the naval command to the minitry meant completion of the program time rose from eight to twelve months, so five behind schedule.
A set of Revolutionary Features
Design of the Type XXI Island
Aft view, from the reconstructed plans based postwar on the Whilhelm Bauer.
Hull Construction
It was suppose and announced thicker and stronger for deeper dives, and essential part of the design.
Details from the February 1946 British Portsmouth Commission report:
Plating is generally 4 mm (.16″) thick, splinter protection 17 mm (.67″) thick provided for the bridge and gun positions across the top, along the sides and at the ends. The material for the splinter protection is identified as “Wsho/Mo”, but its characteristics are not known.
Citing “The vertical keel extends aft from the fabricated forward structure, forming a deep centerline division extending up through the forward trim tanks and WRT tanks, to the forward end of the forward battery, where it is reduced in depth to 285 mm (11.2″) and extends aft at that depth to the after end of the after battery, except for the section in the way of the variable tanks, which is carried as a centerline bulkhead up to the pump room deck. Aft of the after battery it is carried at the full depth from the sole plate to the bottom of the pressure hull as far as the forward end of the after trim tank. It is carried aft through the after trim tank, but does not extend below it, as the longitudinal member at the bottom of the vessel is a bulb tee 120 x 6.5 (4.72″ x .26″). Connection is provided at the after end of the trim tank to the cellular structure which carries aft into the tail of the vessel”.
And also: “The stern frame of a casting (a weldment is permitted by the specifications) with carriers for the rudder and for the stern planes. Also at the after end of the vessel is a pair of fins which serve the dual purpose of stabilizers and struts for the propeller shaft bearings. As shown on plans, the fins are the widest part of the vessel”
Overall: “The hull structure is an interesting solution to the problem presented, and is a radical departure from previous German practice. At the same time, a number of the design details could have been improved. A number of details characteristic of previous types have been retained”
As for the critics, also noted by the German themselves:
-The method of connecting the upper and lower segments in the way of the battery compartments is generally faulty.
The commission also noted (absent from German reports):
-Noted failure of the lower segment under test below the designed value.
-External frames are deeper, but their are close to earlier vessels.
-Flanges have not been widened to improve the lateral stability of the frame section
-Unsatisfactory bulkheading, with collapsing pressure 50% as the designer’s spec
-Retention of bolted plates, rivets in shear is questionable.
-Weakness in the interruption of the circular section at the bottom of the vessel,
substitution of a heavy sole piece and,
additional deck and floors, detrimental to the stress distribution.
Powerplant
Hertha electric engine of type XXI Siemens-Schuckert AG 1944
As a matter of fact, despite the absence of a Walter Gas turbine, the Type XXI was a diesel electric, equipped with three powerplants for various uses:
Two MAN M6V40/46KBB
Diesel assembly into the first powerplant section (the second had all four electrical motors)
6-cylinder diesel engines, rated for 4,000 PS (3,900 shp; 2,900 kW) For surface navigation. They were used to power the Batteries, were lighter units, taylor-built for the Type XXI since space needed to be gained for more batteries, and on paper, were less powerful than those onboard the Type IX/VII.
The only way to mitigate that shortcoming was to add a supercharger using exhaut gasses, workong at 520 RPM Max. The major problem is that these new injectors were deficient when the Type XXI was produced, and proved to be woefully unreliable, leaving the diesels to their lowest basic output. As a result, surface speed suffered. As a comparison, the Type IX-D/42 had 9,000 horsepower (9,100 PS; 6,700 kW) for more than 33 kts.
The second point of interest was the schnorchel, which was supposed to feed the diesels underwater. This innovation was already applied to the Type VII and IX, however the system onboard the Type XXI was created with a new valve system for heavy weather (see later). Nominal surface speed was to be 15.6 knots (28.9 km/h; 18.0 mph) surfaced.
Two SSW GU365/30:
Battery accumulators (Bauer)
Double-acting Hertha electric motors from Siemens-Schuckert, with an output of 5,000 PS (4,900 shp; 3,700 kW) at 1675 R.P.M. These were the main electric units, bringing far more power (five times more) than the Type IX. The latter, which were lighter, had the SSW 1 GU 345/34 rated for 1,000 PS (990 shp; 740 kW). These were supposed to provide 18 kts to the new boats, later re-rated at 17.2 knots (31.9 km/h; 19.8 mph), versus 7.7 knots (14.3 kph) for the Type IX, but in reality were re-rated by postwar assessments to 15.
Two SSW GV232/28:
Silent Running electric motors. This new system was to provide a stealthy final approach (inside the convoy). Howeve that feature was at the time too advanced for the allied tech, largely relying on active sonar systems. Also built by Siemens-Schuckert, they provided 226 PS (223 shp; 166 kW) at 350 R.P.M., for 6.1 knots. As for batteries, Six battery divisions, each with 62 cells and 1300 A.Hr. (Cell type 44 MAL 740E) were provided.
Sas/hatch to the Machine Room
| ⚙ Performances (British report) |
| Cruising range – normal |
15,500 mi. @ 10 kn. 2 engines |
| max. speed |
11,150 mi. @ 12 kn. 2 engines |
| submerged |
365 mi. @ 5 kn. 2 engines |
| // |
285 mi. @ 5 kn. |
| // |
170 mi. @ 8 kn |
| // |
110 mi. @ 10 kn |
| Surface speed – max. |
15.6 kn. |
| Submerged speed – 1 hr. rate |
17-18 kn (sustained) |
Range/Autonomy:
The other strong point was the new boat’s range, both surfaced and underwater. The hull was roomier and could accomodate more fuel oil, resulting in a surface speed of 15,500 nautical miles (28,700 km; 17,800 mi) at ten knots (19 km/h; 12 mph). To compare with the Type IX, the latter reached 13,450 nmi (24,910 km; 15,480 mi) at the same speed, so this was a clear-cut improvement, however not really tested or corroborated in post-war tests. On paper, the new Schnorchel was to enable that same autonomy at eriscope depth all the way, albeit at a slightly lower speed.
But the real “game changer” at this stage of the war, was of course their submerged autonomy, which promised to be formidable: They could indeed cruise over 340 nmi (630 km; 390 mi) at 5 knots (9.3 km/h; 5.8 mph) while submerged. For comparison, a type IX could only cruise for 63 nmi (117 km; 72 mi) at 4 knots (7.4 km/h; 4.6 mph) while submerged, a Type VIIC 80 nmi (150 km; 92 mi) also at 4 knots (7.4 km/h; 4.6 mph). So this was, on paper, 3-4 times better, allowing an U-Boat to start from the Jade estuary, Wilhelmshaven, then reach the confines of the Gulf of Gascony (Bay of Biscaye), or well past Scapa Flow in Scotland. With the new Schnorchel it was even possible to reload the batteries while staying at periscopic depth.
Submerging faster, Diving deeper
Other points that were specified to escape allied escorts, was the ability to dive fast, 20 kts on paper, and dive far deeper than any other u-Boat before. The first was achieved thanks to more filler ports along the outer hull and even the island, and a deeper, larger hull with more capacity, added to more powerful bilge pumps, hydraulically powered.
To dive deeper (Up to 300 m, which was the theoretical crush depth) enginers simply made the pressure hull far more thicker, and this was provided by Dönitz be granted by Speer and extra provision of high grade steel. The issue there however, was entirely related to the construction method by separated modules: The way they were jointed together was absolutely crucial for structural integrity.
But at the end, the Type XXI were able to dive at a test depth of 240 m (787 ft), 10 meters miore than the Type IX, and same for the VIIC, which was less than the 280 m anticipated. Some post-war tests rated this even only at 200m. So overall it was marginally better, and construction defaults had it toned down further.
It shoyuld be noted also that, if the hydraulic system was to fail, there was an emergency backup system for the steering.
Armament
Torpedo Tubes
The Type XXI were the first to get rid of their stern torpedo tubes. It was found that firing their torpedoes submerged, using the new acoutic system was enough of an advantage, and getting rid of stern TTs spared spaces for the powerplant. So the Type XXI ended with just their six forward torpedo tubes, always the standard 21 inches (53,3 cm). These tubes could fire a larger variety of torpedoes than all previous models through, had a revolutionary loading system (see later) and could also launch 12 mines also via the tubes.
New Torpedo Models
Type XXI Plate III, S75, torpedo reloading slide, cut
the Type XXI was equipped with several torpedo types. The normal ones, which need aiming first:
-The “Lut” or “Fat” which run in a straight-line for a while, then turn repeteadly, sailing in “zig-zag”.
-The “Zaunkönig” was the late acoustic torpedo version or G7e TV, following the propeller noises of the destroyers. These cannot evade it unless they say full-ahead, because this torpedo is a bit slow.
-The improved version T11, also acoustic, following destroyers and ordinary vessels but was faster and cannot be diverted by noise devices.
In practice, the Type G7e was the main supply. As a reminder, this torpedo was provided as the late types G7e(TIV) Falke and G7e(TV) Zaunkönig.
The Falke was the model allowing a sub to fire them while deeply submerged inside the convoy. Their main advantage was to start like a straight-running torpedo for the first 400 m (440 yd) to enable its acoustic sensors, then actively search for a target. Since this equipment was sentitive, the propeller needed to be as quiet as possible, by its shape, and also speed, at only 37 km/h (20 kn), while the Carrier sub was also to be dead silent. This model was mostly intended for merchant targets. its use was limited, as it was merely a “proof of concept” for the acoustic homing torpedo.
The common model however was the G7e(TIII) of 1942, straight-line model capable of 7,500 m (8,200 yd) at 56 km/h (30 kn). It was declined in 1943-44 into the G7e(TIII Fat II), and LuT (Lagenunabhängiger Torpedo), or the G7e(TIII Lut II) all pattern-running systems for convoy attacks. They made their course unpredictable.
Automatic Reloading System
Standard reloading system,external.
As noted in a confidential report dated February 1946 from the Portsmouth naval commission which investigated the Type XXI, REPORT 2G-21, S75-3 was about Torpedo Handling, loading and stowage states the following:
Although several of the design details of the handling, loading and stowage arrangements from earlier German types were retained on the Type XXI, the basic conception, to provide stowage for all torpedoes within the torpedo room with a ready means for servicing the torpedo tubes, was an innovation in German design. The stowage and handling arrangements adopted provide an interesting comparison with present U.S. designs. Several noteworthy features, in particular, the elimination of heavy stowage cradles, warrant consideration for possible inclusion in U.S. designs.
The basic hull design of the Type 21 submarine made it desirable to eliminate the topside stowage existing on the preceding types that were not designed primarily for high submerged speeds. Also as the requirement of a narrow cross section aft eliminated the possibility of after torpedo tubes, it became necessary to provide adequate stowage facilities for all reserve torpedoes in the forward torpedo room.
The German design to obtain this is shown on Plates I-IV. The functioning of this arrangement with torpedoes is fully discussed in the NavTechreport.
A limited number of mines can also be handled with this setup by the addition of the special supporting chocks shown on Plates VI and VII. 18 TMB mines (7.6 ft. long) or 12 TMC mines (11.2 ft. long) could be carried external to the tubes. When carrying mines but a third of the available space is utilized as only the inboard chocks (and cradles) are used. With the present U.S. designs the same cradles that are used for stowage of torpedoes can be used for the stowage of mines; a total of 16 mines (10 ft. long) forward and 12 mines aft are carried in the cradles.
The present German design has proven faulty under depth charge tests in that the elastic bolts securing the supporting arms to the pressure hull have sheared off. This arrangement provided for a total of 20 torpedoes, 6 in the torpedo tubes and 14 in the stowage. Three cradles were left empty so as to permit servicing of the torpedoes in the tubes. No berthing was installed within the torpedo room; adequate facilities for berthing the crew were provided within the large battery compartment.
Noteworthy Arrangement: The basic arrangement providing reserve torpedoes on the same level as the tubes to be serviced with a ready means of athwartship movement of the torpedoes on their supporting members is the same on both U.S. and German designs. The German design utilizes power to move the torpedoes both athwartships on their support arms, and into the tubes longitudinally, while the U.S. designs depend on rollers and hand control for similar transport. The relative advantages and disadvantages of hand control versus power control essentially balance each other.
The main advantage of the Type XXI arrangement lies in the overall weight saving by the use of chocks in lieu of cradles for the support of those torpedoes not lined up with the tubes. The cradles, less rollers, weigh 780 lbs. The chocks used weigh 75 lbs., or 150 lbs. for each torpedo, effecting a saving of 630 lbs. per torpedo.
The conservation of weight by using chocks on rollers in lieu of cradles, and by reducing the number of cradles to one for each layer of tubes, could be easily accomplished on existing U.S. submarines, if desired. This would, at the same time alleviate the awkward handling and stowage problem that now presents itself with a large number of empty cradles. It is to be recognized, however, that in order to carry mines it becomes necessary either to use additional special fittings, as in the case of the German design, or to retain the present stowage cradles.
CONCLUSION: The design adopted for the Type XXI submarine meets the German requirement to provide rapid, silent handling and maximum torpedo stowage facilities within the forward torpedo room. It does this at sacrifice in living accommodations (within this compartment) and overall mine stowage capacity. To properly assess a comparison of this arrangement, it would be necessary to know and discuss the effects that higher submerged speeds would have on the overall arrangement of a similar U.S. design. This is beyond the scope of this report. However, special noteworthy features present interesting studies for possible adaptation to and improvement of present U.S. designs. The lightweight chocks and cradles used are of particular interest. It is recommended that further study be made of an arrangement that uses light chocks in lieu of the present heavy stowage cradles so as to determine what sacrifices, if any, are necessary and what overall benefits are derived from such a change.
The key “pusher barillet” system to hold and distribute torpedoes
Torpedo handling, vertical view.
AA Guns
The two tailor-designed turrets house each two 30MM anti-aircraft guns, mounted on each end of the conning tower fairwater. For traverse, elevation and firing, they are controlled by the gunner, obtained by the main hydraulic system, with simple and directional controls. They are not remotelly operated as sometimes seen. The motors were close to small oil pump systems.
Each turret contains two pressure-tight ready service tanks, housing 250 rounds each, plus a gunner seat, with foot controls and related hydraulic gear, hand controls for the elevation and traverse. The 3 cm MK 303 (Br) Flak also called Flakzwilling (M44) was experimental in 1944, designed to replace both the 20 m and 37 mm FLAK, fitted on fixed or wheeled chassis and in specially created mounts for the Type XXI. Manufactured by Krieghoff in 1944, they were 222 delivered in 1944, 190 in 1945.
| ⚙ Krieghoff 3 cm MK 303 (Br) |
| weight |
185 kg (408 lbs) |
| full lenght |
3.145 m (10 ft 3.8 in)j/td> |
| Barrel length |
2.2 m (7 ft 3 in) L/73 |
| Shell |
30×210mm |
| Caliber |
30 mm (1.18 in) |
| Elevation |
-10°to ±85° |
| Traverse |
360° |
| Rate of fire |
400 rpm (cyclic) |
| Muzzle velocity |
1100 m/s (3,609 ft/s) M-Schos |
| // HE |
900 m/s (2,953 ft/s) |
| // AP/HE |
950 m/s (3,117 ft/s) |
| Feed system |
15 cartridge clip or belt (Type XXI) |
There is a scuttle in the turret top, from which the gunner’s head protrudes. The forward face is shielded for extra protection, interlocked with the guns, rising when elevates. The turret seats on a ball bearing race, with the carrier ring on the fairwater having an internal toothed ring gear to engage the motorized spur gear. Stops limiting elevation and depression as well as rotation to 170 degrees on each side. When diving, the guns are locked at 5 degrees depression. Construction use the same special steel (Wsho/Mo) as the bridge armor plating, 17MM (0.67 in). It was judged simple enough, although the amount of hydraulic piping is excessive, prone to failure and in act the sole major source of contamination of the whole hydraulic system with salt water aboard.
There was however, as reported in blueprints, a project to replace what was seen as an interim solution, by two pairs of 40 mm guns instead, and that time in full remote operation. Little is known about this arrangement; But it allowed the submarine to fire semi-submerged, or while submerging, or just surfaced without delay, nor risks for the gunner.
View of conning tower fairwater, and turret access.
Sensors & Electronics
Radars
The FuMo 61 Hotenwiel radar and transmitter Type F 432 D2
The Type XXI was given a more extensive radar suite than any other submarine before: There were two working parts, the FuMB Ant 3 Ball radar detector coupled with an antenna fitting, and a FuMO 65 Hohentwiel U1 radar with a Type F432 D2 series transmitter device.
The FuMB Ant 3 Bali radar detector and antenna were located on top of the snorkel head. it was a small device, but with extended range, able to catch radar pulse from 50 km? away. Introduced from February 1943, the Biskayakreuz was replaced by the FuMB Ant 3 Bali with worked on the 137-166 cm wavelenghts, mounted on top of the schnorchel mast. A second oscillator was added (FuMB 1) from July 1943 due to the British introducing the 10 cm ASV Mk.III and type 271 radar not detected by Metox. The latter was retired after it was found to be detected by aircraft.
The FuMO 65 Hohentwiel U1 with the Type F432 D2 radar transmitter were installed on the right side of the conning tower fairwater. The latter was a trusted model designed from 1938 and largely used on planes, surface ships and subs. On the latter, its detection range was limited to 10 km, so it was a “last warning” resource. A plane 10 km away could very quickly be on target. Frequency was 525–575 MHz/57.1-52.1 cm (low UHF-band), PRF 50 Hz, pulsewidth 2 μs, azimuth left 30°, middle, right 30°, and power 24V 30A, Synchronous inverter. It was folded inside a “trench” alongside the conning tower roof to protect it when diving.
Hohentwiel telescopic Mast detailed blueprint.
Sonars: The Nibelung-Parisfal suite.
U-Boats-prowes-Type21-captured
The passive component of the sonar installation, was the Gruppenhorchgerat (GHG) passive sonar installed in the keel (“Parisfal”), under a protruding cover. This system was not “invented” for the Type XXI but already used from 1942 in some older Types VII/IX. It consisted of two groups of 24 sensor, 12 per side, with tube preamplifier each. 48 low frequency signals were routed to a switching matrix. This allowed the sonar operator to determine the direction of the sound source and relative distance. Switchable crossover ranging from 1 to 6 kHz center frequency improved the reception. There was a dead zone of 40° fore and aft, which was corrected on the “full range” installation on the Type XXI. Its detecation range was 20 km for single shis and up to 100 km for an entire Convoy.
Its active component was the advanced “Unterwasser-Ortungsgerat Nibelung” non-line-of-sight system. To make the fullest use the new rapid loading system and acoustic torpedoes fired from deep below, the Unterwasser-Ortungsgerät NIBELUNG mounted in the bow enabled an approach from deep inside the convoy, emit short active sonar bursts to fix the target location, without being detected. The torpedo room worked in conjunction with the sonar, receiving targeting data, which was inputted into the new Lageunabhangiger Torpedo system.
U-3008 Kiosk details
Another innovatove system, the U-Bauer Decoy Ejector, located in the stern compartment. It could sent bubbles and oil to the surface to make think a captain his target has been sunk.
Periscopes
Conning tower design showing the location of the antennae, radars, schnorchel and persicopes.
Along the conning tower fairwater were located the two receiving surface whip antennae, the radio emitter antenna, the main day attack periscope, the smaller night persicope, mosty used for star-based navigation, the main Hohentwiel radar and in front of it, the large schnorchel mast, with the exhaust and air intake tubes, an ball mount admission system. On top of it was located the FuMB Ant 3 Bali radar detector. It seems the periscopes models were less innovative, based on the same models used in earlier Type IX, possibly the type NLSR C/9 day attack periscope. More on their uses and procedures can be found here. The main attack model on the Type XXIII was however the ASR C/6 periscope, with an ocular box of type NLSR C/9 (night periscope and day periscope combined). Possibly the day model was the StaS C/2 attack periscope. The only point to underline here, is that excessive vibrations on the early boats precluded the use of periscopes while under schnorchel’s navigation.
U3008, Hohentwiel and main persicopes. (ONI)
U3008, same, rear view.
Production: “Like sausages”
Albert Speer organized mass production with great efficience as agreed in the Summer of 1943, however the first series would be operational in November 1944, not July as first planned, but later. The first had teething issues and commission was delayed. Prefabricated sections were used, that could be built ashore in tunnels, blockhouses, underground sheds, then transported by boat in immense Block-building sites made by Todt for final assembly. The latter, bomb-proof installation were capable of producing hundreds in a month, at the edge of large rivers.
The final assembly was mostly to be carried out in the Valentin submarine pens, a massive and bomb–hardened concrete bunker, built at Farge, near Bremen between 1943 and 1945, using 10,000 concentration camp prisoners and POWs by Todt. It was 90% completed when bombed in March 1945, using the Grand Slam “earthquake” bombs. cracked open, it was abandoned and captured a few weeks after by British troops.
A feat as spectacular as the submarine itself
Crude section
Section in construction, central module.
The mass-construction of the Type XXI at the same path of the American libery-ships, for the most sophisticated submarine ever built was a great accomplishment by German planners at all level, under constant day and night bombings. The total order, in 1945 was to reach 1,170 Type XXI alone, and more than 2,000 Type XXIII, while the entire submarine production until that point in Germany was 1,043. The game changer was a complete reorganization of the production for maximum efficiency, befitting to a “total war”. At last by late 1943 Germany adopted standards of the allies, producing more with less, sparing materials, simplifying, cuttiing work hours, better employing skilled labour, using masses of slave workers in less skilled tasks, but trying not to compromise too much on the technological edge.
The first serious bottleneck was found in the dual requirement for a rapid setup of mass production while maintening the same delivery rate for existing older types, for a 6-months transition. This necessitated indeed the provision of twice as much materials, as well as manufacturing capacity with a network already saturated and stretched to the absolute maximum. At the worst case scenario, the full transition was to be performed over eight months.
Far more materials needed
Prefabricated scheme
Step up the production of U-boat batteries soon appeared paramount, as the new types asked twice more, added to the old types. To achieve this the Armaments Ministry’s had to produce the requisite machinery and equipment for at the expense of current contracts but for aircraft production, which between all arms was given absolute priority. The sheer quantity of lead and rubber needed for them grew acute, but this was later overcome.
The Type XXI also needed very powerful electric motors, outside batteries, that needed to be developed, and the boats were also using many other electrical fittings. This included the cruising motors and trimming plus bilge pumps as well as the new, powerful echo-ranging gear and associated underwater listening station, equally modern and powerful radio and radar sets, search receivers, which at this point focused the attention of the entire German electrical industry, curtailing production of replacement power-stations and locomotives for those destroyed by the bombardments. The population suffered as the result of these shortages.
Another issue was to gather enough high-grade steel plating for the pressure hull. On this particular topic, the Heer was adamant it needed all the capacity to produce larger and better protected tanks: This commodity constituted indeed the worst bottleneck for the German industry as a whole. The allies had the same problems, and in both ship construction and aviation, wood made a comeback. The old type VII still needed these supplies, and the new types, larger, required more. But the autumn of 1943, the output needed was 3.5 times greater as what was allocated until then. Soon, the Kriegsmarine had to make choices, like cancelling all surface vessel production, stopping ongoing contructions (like the many times postponed Graf Zeppelin, cancelled for good), and even warships repair was cancelled or further prioritized (like the Tirpitz). Shaping ready rolled pressure-hull sections was also a challenge.
At this point, the Gamble of the Type XXI was a nightmarish one, especially for one man, the director of the Central Shipbuilding Committee, Herr Merker. There was indeed a Considerable risk involved in mass-producing this new U-boat without trials or standard development phase. Failure was not an option as the prodigious efforts needed would have been in vain, especially of up to 200 new U-boats were to be scrapped in the end. This was double risk as developed alongside an unprecedented level of prefabrication with mass-production methods never used in shipbuilding before in Germany. And if this was not complicated enough, wartime conditions took their toll in a semi-predictable way all along. If a major supplied was destroyed, the whole supply chain was too, triggerring massive delays in delivering an intested type that was badly needed to reverse the situation at sea.
In fact many experts of the time were worried that completing the task as early as possible was an unsurmountable task overall, but this does not prevented a firm order for 360 Type XXI and 118 Type XXIII to be passed, added to a Mediterranean ports extra order for 90 supplementary Type XXIII. New specialized, smaller and simpler types of both were also studied for future production in 1945. The Type XXI/XXIII production was to create a basis for future developments, testing the waters.
More delays before and after commission
Even if Boats were completed on time, having crews trained on board, on such brand new boats, was not as simple as it seems. A ship and its crew needed to work like a tightly, well oiled man-machine clock. No procedure was ever done for all new systems designs, and documentation was provided along the way. With the initial production delays showed above, the whole new U-boat building programme dropped five months behind schedule. And meanwhile, crews needed to be assembled and trained on boats that were still unfinished.
The first or these U-Boats was launched as scheduled in April 1944, but needed a lot of extra work to fix its multiple issues, that would have been normally avoided if sections has been perfect. So it’s onli by June 1944 she was officially commissioned. The start was slow but after December 1944 it was believed that a rate of 20 Type XXI would be completed monthly, meaning finding and training 57 men each time (so 1140 monthly) was not easy. Shortcuts were found, as captains, usually taking command during completion, visited the boats from time to time, but mostly trained in dedicated building, on sub-sytems when available, trying to reproduce a semblancy of working environment with limited means.
Even when the crew entered the boats, after commission, actually starting proper training, at leat on the first seven boats, frequent interruptions for repair and modifications allowed the initial crew to train in not three months as it was usual, but six. Constant reporting along the way and close co-operation between the Construction Office (Blankenburg) and U-boat Acceptance Staff, plus the U-boat Training office eliminated all most serious defects in a few months. By the autumn of 1944, all these informations has been passed onto the while construction chain and incorporated into newly-built boats; The normal crew of a Type XXI consisted in fifty men and seven officers. To compare, a larger Type IX was about the same, about 56. But with a much tighter space and far worse living conditions.
⚙ Type XXI class specifications
|
| Dimensions |
76.20 x 8 x 6.32 m (252 x 26 x 21 feets) |
| Displacement |
1,621 tons standard, 1,819 tons Fully Loaded, submerged |
| Crew |
57 (5 officers, 52 sailors) |
| Propulsion |
2 shafts MAN M6V40/46KBB supercharged 6-cyl. diesels 4,000 PS
2 SSW GU365/30 double-acting electric motors (4,900 shp)
2 SSW GV232/28 silent running electric motors (223 shp) |
| Speed |
15.6/17.2 knots (29/32 km/h) or 6.1 kts silent running. |
| Range |
15,500 nmi/10 knots surfaced, 340 nmi/5 knots submerged. |
| Armament |
6×53.3 cm (21 in) TTs bow, 4×2 cm C/30 FLAK turrets |
| Max test depth |
240 m (787 feets), estimated crush depth +300m |
The Type XXI in action
Ed Tambunan colorized photo of the surrendered U-3034, May 1945. Note the yellow markings.
In early 1945, the Allies were prepared to strike Germany from the South, East and West. The ports in France had to be abandoned and the ships were withdrawn to German, Danish and Norwegian ports. The training divisions had to abandon their training places in the Baltic one by one: Pillau, Danzig, Gotenhafen… But despite of that, they went on with the trainings with the new vessels —now that they were launched in droves— hoping to fight until the last moments.
In the last days of April 1945, U-2511 sailed from Bergen, Norway. She went away from her sisters and gained speed as for the first time, a Type XXI would face the enemy. Men on board were already well trained and knew that they could trust her to sail fast and be kept submerged for a long time. Within days she would fight the enemy, show that all the expectations on her were right. She was commanded also by an ace, Korvettenkapitän Schnee, U-boat veteran with 200,000 tons sunken in seventeen engagements and since her had worked for the Naval Construction Commission, perfectly in tune with the Type XXI and its capabilities…
Two sorties and a controversy
Crew of U-3016 in 1945
U-2511 and U-3008 were in fact the only Type XXIs used for operational war patrols, in actual combat. … but neither sank any ship. The first’s commander claimed to have spotted a British cruiser on 4 May 1945, just when news of the German cease-fire was received and that he made a successful mock attack before leaving the scene undetected. U-2511 trained in the 31st U-boat Flotilla from 29 September 1944 to 14 March 1945 and then the only active 11th U-boat Flotilla from 15 March to 8 May 1945 under command of Captain Adalbert Schnee, making her first an last patrol on 3–6 May 1945.
However postwar analysis had completely disclaimed Schnee’s accounts as dodgy at best. It happened that already during his ten combat patrols on U-60 and U-201 he overclaimed 50% of this kills. According to cross postwar records, he did not departed on 30th april, but 3rd of May 1945 from Bergen, could not spot HMS Norfolk escorted by destroyers, as there were none, could not spot the cruiser again on 5 May off Beegrn as he was there on the 6th, and at that time, HMS Norfolk was NW of the Shetlands, bound for Scapa. He also claimed to have been taken onboard the cruiser for interrogation, which was just straight out impossile as the sub did not surrendered before the 9th, and no record of his interrogation as noted in the cruiser’s logs. Also his “eye witness”, war correspondent Wolfgang Frank was not aboard when Schnee made his “mock attack”.
Later in 1988 the investigating Gröner group was joined by Dr. Niestlé, could not find U-2511 log,s but had the one from Norfolk, and now declassified Ultra decripts pointing aout the position of U-2511, interviewed eye witnesses, and it appeared his boats hat day at 8:00 on the 5th was 110 miles south of Norfolk. He did not evaded a Corvette on the 4th allegedly, as she was too far away to the west, nor Norfolk, too far north from U-2511.
On her side, U-3008 left Wilhelmshaven for her first and also last patrol on 3 May 1945, but returned to port after the surrender. On 21 June 1945, she was seized by the Allies in Wilhelmshaven, and sent to Loch Ryan. From there, she was transferred to the United States and reached New London in Connecticut, on 22 August (see later US evaluation).
All in all, for 121 boats “commissioned” before V-Day, only about half were ever operational, making a few sorties after a training period. The very first boats completed wee riddled with problems and only fully operational by the mid-1945. Apart two active war patrols, the others performed short semi-operational training cruises. There were losses, even though no ship was ever sunk, traducing the extreme state of affait for the Kriegsmarine that late into the war: U-2503, 2509, 2514, 2515 and 2516, U-2521, 2523, 2524, 2530, 2532, 2534, 2537, 2542, 3003, 3007, 3028, 3030, 3032, 3505, 3508, 3512, 3519, 3520 and 3523 were all lost, between enemy action (in the most cases, not ASW action but rather air attacks, including in ports) and other due to accidents. In fact the attrition rate was revealing in the production rush and problems with the whole concept. The remainder surrendered or were scuttled.
General assessment: Debunking the “wunderwaffe”
cutaway_Type_XXI
Reality’s ugly head postwar basically destroyed the optimistic views/outright propaganda about the initial capabilities of the Type XXI, and it’s postwar myth of “super weapon”. It might be argued that Dönitz was eager to have his project prioritized towards Hitler and stated paper specs that were very tasty but far fetched indeed. The problem is that they were taken as such and publicized in some general public books and, notably in History Channel’s “Nazi Megastructures: Hitler’s Killer Subs”. In this documentary many claims were made.
The latter indeed was supposed to be quieter and diving much deeper than any other sub that came before.
Her top speed was 17 knots based on 5,000 shp.
With her reloading system she had the potential to sink 18 ships in 20 minutes.
Her diesels could reload her batteries in just one hour
Despite a much larger hull, the streamlining meant her acoustic signature was much smaller
The schnorchel was ingenious, allowing her to stay underwater even in rough weather
Her sophisticated echo chamber could identify, track and target multiple targets at once, so she could blindly fight from 160 feet deep.
US evaluation post-war showed the batteries could be recharged, based on far lower output, in four hours, not one. The point on top speed, 17 kts submerged was debunked in several ways. First off, she was designed to dive fast, in 20 secs. as specified. Second, as she was given for this many freeing ports, these added 28% to her drag. During a submerged run on 8th Nov. 1944 U-3506 achieved only 15.93 kts. This was compounded by British own tests, which doubted that 15 kts could be achieved, even with a one hour run. This was also confirmed by a German war log in 1-15 January, confirming 15 knots was achieved.
Also, test bed results for the two main electric motors only achieved 1800 Kw or 2413 hp, which, with fully loaded batteries, could be maintained for just an hour, not 4-5 as stated. Others stats showed 15 kts could ebe achieved at max power for just 50 minutes. It appeared also that to house the many new batteries, German engineers’s newly developed, lightweight diesels were rated at 1970 bhp and each were given superchargers driven by exhaust gas (turbo).
However it appeared in US tests that these diesels were very weak. On trials they were limited to 1700 bhp due to overheated exhaust gas, and proving hazardous when snorkeling so deactivated, which further crippled the boat’s speed on surface. Without the superchargers, their output fell to just 850 bhp, making for 12 kts on surface, but on paper only, as the British found the boats were “ploughing” and the deck was constantly flooded, creating massive drag, so it fell to 10 kts and below in practice. For loading the batteries, US tests shown this was even worse, with superchargers deactivated, and that 6 hours were necessary at max capacity.
It appeared also the “all-weather” Snorkel was not an innovation of the Type XXI but in reality was found also on the late Type VII and IX as well. What was unique however, was the Type XXI telecopic mast, but it never worked properly: Only 10.9 kts could be achieved due to eddy shedding from the mast and periscope, thus severe vibration reducing in practive top speed to just 6 knots. The British downwards hated this ‘snot head’.
For torpedo stowage, the US reported that idle positions forced a practical stowage of 20, not 23 torpedoes. The British found that if carrying 14 reload torpedoes, six were to be accomodated in the automatic reload system and these needed a classic loading, which took far more time, just as a Type VII/IX. The idea that 18 ships could be dealt with in 20 minites is therefore just ludicrous. There was also the fact the Type XXI was supposed to carry four types of torpedoes, the G7e, and others, making impossible to fire the same way 18 torpedoes.
As per the “deeper diving”, it was not that stellar: As designed, 135 m was the safe depth, 200 the test one and 330 (1073 ft) the crush one. However, when a design defect was found on the torpedo hatch during a 16 March 1945 test dive, a fix was needed, which was successful on 8th May 1945, far too late for operations. Numerous manufacturing defects were also found by the allies which restricted their operatoinal depth to 108 m (350 feets), barely better than for a Type VII (102 m/330 ft) and a test depth at 160m/520 ft. A far cry to the 280 m (919 ft) claimed in the documentary.
About the alleged acoustic stealthiness, passive sonars were not a thing in WW2, as active ones (ASDIC SONAR) were used instead, pinging the hull, which, streamlined or not, bounced back the signal. According to British reports the Type XXI had a larger, deeper hull, presenting even a larger surface on which to ping than a regular Type VII: She was less stealthy. As for the noise, even at 8-9 kts underwater she was established as noiser than a Type VII even running at 3-4 kts ! (Malcolm Llewellyn-Jones).
As for the 260 tonnes of batteries supposed to propelled the sub underwater for 11 days, allied tests deflated this to just less than seven. It was still far better than a Type VII/IX, but still the sole point that stands out. However this was done at great risks. Indeed, postwar British evaluation pointed that after their U-3017 tested in August suffered a battery explosion that crippled her, their enquiry suggested that German practice had caused a number of explosions, possibly not initially taken as loss causes. This was coumpounded by four wartime German engineers reports. Also, it was observed that the electic cables running under the battery compartment were poorly insulated, and water wfrequently seeped in the bilges, causing shorts, arcing, combined with poor ventilation and hydrogen emanations during the charge. Perfect recipe for a catastrophy.
Another innovation point was also debunked: The use of hydraulic power to spare electrical motors, used in fact for the preiscope hoist, bow/stern plates, rudder, TT doors, torpedo reloading and other sub-systems. Toroughly examined by the US and Britsh engineers, the system appeared to have been improperly designed, was over-complicated and too fragile overall for combat operations. The piping and fittings were at the mercy of manufacturing quality and were not made leakproof. Seawater as a result contaminated the network on a daily basis.
A conclusion: A Game changer ?
U 2501 in May 1945, in front of the Elbe 2 bunker with submarines pens near the Hamburg shipyard in Gowaldt. This boat arrived in March-April 1945 while the bunker was built for the final assembly and repair of the Type XXI. The only officer on board was Oberleutnant Engineer Noak, ordering its scuttling. It was flooded at 7 AM, May 3, 1945, before leaving.
The Type XXI sure had qualities, but they needed all more time to be ironed out, to achieve their true potential. The whole program was rushed in such a way it spelled disaster. But outside this, how this boat could be used tactically ? Where these old tactics were still applicable ? – It appeared that first off, the Type XXI actual performances were not ideal for the usual tactic of moving faster than the convoys. Six knots while snorkeling, or 15 kts for 50 min. were not sufficient for this. Daylight attacks were impossible, and only nigh attacks could have been planned, just like the old Type VII.
As for communications, this was possible for the Type VII to report a location and course to the others in the wolfpack, by radio for coordinated attacks, but it was impossible for submerged Type XXIs. Another set of tactic was then need to reach the potential of this new submarine.
The German HQ knew about this, and planned for these “Wunderwaffe” individual “free for all” operations, like in the early days of sub warfare. Operations in shallow waters was ruled out, and only oceanic ones were possible with that kind of boat, with the understood limitations of the absence of direct route after the lost of the French and Dutch coast. When captured and interrogated, officers stated that indeed, they had received no operational tactics or even a coherent concept of operations. At first, they operated alone, but wanted a return to the pack tactics, perhaps using the new “burst” radio tranmitter.
Pictures of the Hamburg/Elbe shipyard after the surrender. Eight submarines are visibke: U 5052, U 3042 and U 3056, and behind them U 3053, U 3043 and U 3057. A bomb explosion disloged U 3052 and crushed it. U 3042 nearby had its bow significantly damaged. Nearby in the adjacent portico, U 3060 (right) and U 3062 (left) could be seen, behind them U 3061 and U 3063. Racks are visible in another, for completed boats on April 18-20, 1945 with the U 3050 and U 3051 and U 3058, U 3059 located on the slipway nearby.
As for the possibility to locate and attack convoys, true, less boats could do a bit more. There were on paper 90 Type XXI commissioned in January 1945, but their complexity meant contrary to the Type VII of which 12% were at eas at all times, this was true for less tha 5% for the Type XXI. But they were able to make 110 miles per day instead of 60, so making possible to have 12 to 15 of them at all time in the Atlantic, a far cry to the 50 in March 1943, and less in “Black May”. Since the Luftwaffe had lost most of her FW-200 long range recce planes, finding a convoy would have been more a question of luck.
The sole paper found in the achives about the operational mode of a Type XXI to attack a convoy, alone, was to make a submerged approach to a convoy, preferrably diagonally, from forward of the beam, penetrating the screen at slow speed, underwater fully or at periscope height and then find an angle and fire a salvo of six LuT torpedoes. Next it would submerged, dive under the convoy to reload, keeping contect with it through the Nibelung Asdic and GHG hydrophones, reporting movements on a polotting table, enabling firing from deep two more salvoes.
The third and last one was followed by the boat remaining deep for two hours, and then escaping at slow speed, with 15% of her battery power until then and 80% in all by using this methodology. This implies that the boat was to surface afterwards for the long reload (up to 6 hours !). That meant an approach at noon if possible, and attack before midnight until one hour AM, and escape at around 3H AM, and a reload until dawn and in few hours in the morning, thus keeping a marging of safety for crash dives due to aviation during the remainder of the day. Knowing the enormous resources for ASW warfare of the allies in 1944-45, it was unlikely a captain would have use this tactic, knowing that he had only 20% batteries left for safety.
In the end, it is Erich Topp, Konteradmiral of the Bundesmarine until 1969, former U-Boat ace and expert in German sub-warfare in 1944, also commanding two Type XXIs, which in his 1970s memoirs judged that:
The boats did by no means live up to the boasts that Dönitz had made to Hitler and us U-Boat officers… Compared to the older Type VIIC boats, the Type XXI version undoubtedly represented progress and innovation. But it could never by itself have turned the tide on the war at sea, let alone in the overall conflict”.
He estimated anyway that an U-Boat commander needed to keep at least 60-70% battery capacity at all times to face any emergency.
So it seems clear that, unless the whole allied froze up in 1944, enabling one year to the German HQ to improve production and iron out defaults on their design, having more of them, trained with the right tactics… the Type XXI as it was indeed, could not change anything in the “real word”. It’s “wunderwaffe” status was only one of propaganda at the time.
A “wunderwaffe” that nailed the Kriegsmarine’s coffin
In the end, Dönitz’s enormous demands of materials and resources for this project accelerated the defeat of Germany, not helping the war effort one bit: As stated by Naval War College Review, Marcus Jones—an associate professor at the U.S. Naval Academy, “the program cost the war effort some five thousand tanks, a very consequential figure, and could be said to have hastened the defeat of Germany on the Eastern Front”. Because in the end, and despite having schedules respected at enormous cost and stress, there were just too many teething problems to fix still, resulting in two submarines ever truly operational on 90 commissioned, and a third lost mainly due to air attacks, for no kills, not a single allied vessel sunk.
One could argue that was also true for all others “wunderwaffe” of Nazi Germany in 1944. Eating a lot of resources that could have been turned to mass production or existing, trusted weapons systems, and a distraction in the war effort. An “irrational faith in technology” that plagued the country’s Nazi clique in the end. The lackluster results of the Type XXI, in which Dönitz gambled everything, is arguably the worst, most abject failure of any “Wunderwaffe” of the third reich. In the end, it’s legacy was rather a technological one -if anything positive could be learned for it. The Type XXI redefined the submarine type and made it the formidable naval asset it is today. It took the nuclear energy as a substitute to hazardous AIP, but the basis of what a submarine could be, were all setup by the last German U-Boat. This even had some long-term benefit for the Bundesmarine, which modern conventional subs met huge export success on the International Market, somewhat a recoignition of these earlier technological advances.
Other Elektrobbote
Type XVIII, the abandoned Walter boat
This U-boat was the original 1943 project for a main attack model using the Walter propulsion system. Only two, U-796 and U-797 were laid down in 1943. Construction however was cancelled in March 1944. In many aspects they precluded the famous Type XXI, albeit smaller and lighter due to the smaller Walter turbine. The whole complexity of the Walter system would have doomed any scale production of reliable boats before the end of 1945.
Type XXII Küsten Walter Boote (1943)
type xxii
A Coastal submarine type, with only two prototypes U-1153 & U-1154 built at the end of the program. U-1153 was laid down on September 30, 1943, but the contract was canceled on November 06, 1943. The “Advanced coastal boat” was rather short and stubby (see picture), intended for coastal and Mediterranean use. They used the Walter propulsion system. The crew was limited to a couple of officers and 10 men. Three torpedo tubes, with two at the bow and one aft was all their armament, with limited refills. The program noted the delivery of 72 contracts to Howaldtswerke (in Hamburg and Kiel) of which only two were delivered. The situation quickly deteriorating in the Mediterranean changed priorities. It was not specified if the boats had to pass through Gibraltar or were to be assembled locally after shipping them by rail and sections.
Dimensions: 27.1 x 3 x 4.2 meters. Surface displacement: 155 tonnes at 7 knots, Diving Speed: 20.1 knots, Propulsion: 1 x Diesel 12 cylinders Deutz R12 V26/340, 1 x Walter turbine 1850 hp Electrical: 1 x 77, Gas-Oil capacity 12 tons + 30 tons of H2O2, Armament: 3 torpedo tube 3 refills, Range: 1150 nautical miles in Surface at 6.5 knots, 96 nautical miles in Diving at 20 knots. Crew: 12
Type XXIII Kleine-Elektroboote (1945)
type xxiii
Conceived on the same basic request as the Type XXI, Types XXIII were a simplified coastal version of “Elektroboote”. They were to be commissioned in 1944-45 by the thousands, produced in prefabricated sections and launched from the same gigantic factories under bunkers on the great German rivers. In particular, they had only one engine similar to that of the XXI type, but with dimensions and tonnage giving them excellent performance, better than the XXI. They were in fact the fastest submarines worldwide at that time, reaching speeds unheard of.
Their limited area of operations included the British Isles. Their internal dimensions were so small that they only loaded two torpedoes in addition to those already housed in their tubes, which limited the duration of their mission. In the end, 61 boats were commissioned (out of more than 300 planned, later discovered in completion or laying in sections), six of which were able to operate around the English coast in January-March 1945. Scuttled shortly before the capitulation, none was sunk in action, but they actually had better success than the Type XXIs.
Unlike the latter, their radical concept born from desperation did not influenced future development of conventional attack submarines. They were a “viable” complement to the innumerable micro-submersibles built in mass at the end of the war, whose fate was written in advance. A future dedicated post will be made on them.
Technical specifications: Displacement: 234t surface/ 275t submerged, Dimensions: 34.60 x 3.40 x 4.30 m, Propulsion: 1 propeller, 1 diesel MAN, 1 electric motor, 1 schnorkel, 580/615 hp and 15/22 knots surface/submerged, Miscellaneous: Crew 14; Range: 6000 nautical miles at 10 knots, crushing depht 180 m; diving speed 15 sec. Armament: 2 TTs 533 mm (av, 2 torpedoes).
Other Projects
Type XXIV (1943): The Type XXIV was a 1943 design for an ocean-going boat using the Walter system. The blueprint counted 14 torpedo tubes, six bow, but also four each side, aft, which was pretty impressive and never match by other submarines types. Type XXV (1944): The Type XXV U-boats had an electric propulsion on the same style as the Type XXI, but for coastal use. The main reason was also that fossils fuels became a rarity in Germany at the time. This was a 160 ton design but the crew was 58. Armament was limited to two torpedo tubes in the bow. Type XXVI (1944): This Type XXVI was a small high-seas model with its bow fitted with the Walter system. The crew was limited to three officers and 30 men. The Type XXVI was armed with ten torpedo tubes: Four forward plus six in the “Schnee organ” arrangement but and no deck guns to keep a streamlined profile. 100 contracts were initially awarded to the Blohm and Voss yard in Hamburg numbered U-4501 to U-4600. Production was indeed started with sections already under construction for the four boats U-4501-U-4504 when the war ended.
Allied evaluation of the Type XXI
British Evaluation
UK obtained U-3017. The three innovations were all considered with great interest: The Snorkel for example was seen as a viable invention, at least on paper, but in practice, heavy weather in the north sea and north atlantic basically precluded its use most of the time, as shown by GUPPY’s crews operating with NATO in these areas in the 1950-60s. The snorkel was not brushed aside but iot was recoignised a better system was needed to make it viable on the long run, notably longer flexible systems for example, already tested on tanks by the Germans for Operation Seelöwe, the planned invasion of Britain.
The second innovation, the Walter turbine, was also considered with great interest, but after evaluation was found too risky, and dependent on a chemical compound that was hard to procure, and overall not that reliable for combat. They came out with the same conclusions as the German commission evaluating Walter boats, eventually uling this systm out and going for the Elektroboote.
The third innovation, the massive electrical output for greater speeds, was considered with the greatest interest for more direct applications. It was simple and reliable, and while testing the war prize Type XXI, U-3017, commissioned into the Royal Navy as HMS N41, the concluding all existing escorts would find attacks on a 17 knot submarine far more difficult. The early GUPPY, USS Odax managed to outrun a destroyer escort in exercizes, not once, but several times.
These faster submarines could out-range wartime sonars with ease and escape detection altogether, until reliable long-range sonars such as the US SQS-4 and equivalent came about. As late as 1973 Soviet submarines still relied on speed, rather that deep diving or silence for evasion. The HMS N41 was used for extensive tests until being scrapped during November 1949. During these, the staff found the new type more practical in intermediate speeds and underwater endurance at low speed rather than systematic high speed.
They also considered increased torpedo performance allowed fast submarines to attack from beyond sonar range, so they worked out new tiorpedo models (WW2 Japanese influence also counted a lot) and so range was tripled, speed increased. They considered the use of homing and pattern-running torpedo, adjusted for any target angle. Periscope ranging radars for torpedo fire control were to be improved looking at what the German developed for their own Type XXI, with generally better scopes. The new tactic being developed was around limiting areas of approach.
The Royal Navy concluded that a 15-knot underwater speed was not improving survivability and their own WW2 experience dictated that a sub would be detected anyway, and counter-attack with homing torpedoes was the best way. They envisioned with these new boats a next tactical step, the underwater wolfpack coordinated by underwater telephone. Fear of detection for them was over-rated as it rarely happened overall, and even in that case it was transmitting directly at an escort at high power, an unlikely, very inlucky case.
1944-1945 two courses of actions were defined, submarine development with this new propulsion technology, and concurrently new countermeasures and new ASW concept as a whole, integrating the snorkel (“snort” in the UK) fitted on ll subs, but improved and only used in the right conditions. The “A” class, which was still under construction in late 1944 had one early version, first tested on HMS Truant in 1945, and planned for the III batch, and later retrofitted on the entire “A” class and others of the earlier WW2 fleet, like the “T”.
The programme was done rapidly after the war, while an improved “A” class was designed, with relatively minor change initually until modified in July 1945 by Flag Officer Rear Admiral George Creasy, or the Pacific, at the time with Japan still at war. He wanted an equivalent of the XXI, with a large battery capacity combined to a snort and refined streamlining, no deck gun and new fin. There was hope that also to use a more reliable British version of the Walter turbine, but this was ultimately rejected for a purely experimental British Walter boat, HMS Explorer. Meanwhile, the A and T were entirely rebuilt and improved in the 1950s. The postwar Porpoise class was in fact closer to the original Type XXI. The HMS N41 was eventually discarded in 1949 and BU.
USN Evaluation
U-2513 off Key West tested by the US Commission
A classified report was written and sent to the Chief of Naval Operations, in July 1946, about the U-2513, a brand new Type XXI electro-boat allotted to the U.S. Navy as war prize. She was previously commissioned and commanded by Erich Topp, a famous U-Boat ace but had very little time to work out the crew training to their complicated machine and arrived too late to actively participate in the war.
Superficially at first, the US crew was quite impressed with with her top speed submerged under sea trials, and the way it was achieved, through six sets of storage batteries, 372 cells in all, enabling her to quietly sprint at about 16 knots for about one hour. It was deemed sufficient to escape from any ASW vessel at the time. Alternately, she could cruise submerged at slower speeds but for many, many hours, thus also giving all chances to escape after an attack ro taking all the time to approach her target unspotted.
The next most impressive feature related to, was her Schnorchel (snorkel), a breathing tube/mast having both air intake and exhaust ducts. Having the two diesels running while submerged was another great advantage, as long as there were no aircraft in patrol to spot here slo close to the surface… Also it was proven possible to rig one diesel or even both and charge the batteries, still while submerged, so that she could in theory remain underwater for most her mission, another game changer.
The US examiners also were in awe of her periscope optics and passive sonar. They estimated them much superior to USN standards. They were also fitted with an ingenious hydraulically operated torpedo-handling gear, reloading in automatic mode all six bow torpedo tubes in five minutes, with the push of a button. The third reload was just twenty minutes away, so three torpedo volleys could be fired from bow tubes during this period.
When in drydock, the examiners marvelled at the thickness and strength of her pressure hull. It was estimated enough to give the boat a 1,200 feet limit, which was twice the Gato’s safe depth limit. It put the Type XII way below all depht settings among the allies at the time. The sub was also fitted with an equally impressive “automatic pilot” for precise depth-keeping at high speeds.
These details, and others, caused an utter sensation in naval circles, experts al agrees it represented a giant leap forward and close to a “true submersible.”. Howevr admirations about the new boat by US examiners ran dry as they examined other aspects over time, and were less stellar about these aspects. They even reported these as grave design and manufacturing faults, stating in fact that, provided it would have been available one year prior, it could not have made a big difference in the Battle of the Atlantic.
-It was reported about the Type XXI poor structural integrity due to hurriedly prefabricated moduled, in 32 different rather inexperienced factories to assemble eight major hull sections. Examining other boats of the time in Germany, it was established these were crudely, did not fit together properly, so would never reach the planned max sea pressure stated, not sustain close depth charges detonations. In fact the Germans themselves reported a failure at a simulated depth of 900 feet, while the British reported 800 feet, inferior to that of a Type VII.
-Weak diesel engines: The new six-cylinder diesels had superchargers to reach the required horsepower. But it was poorly designed and manufactured, so the diesels could not use these. Therefore the on-paper 2,000 shp went down in practice to 1,200 shp, way too little to have the larger and heavier Type XXI run properly. Top surface speed fell to 15.6 knots, and this lower output also made a full battery charge much slower.
-It was also believed the whole hydraulic system was a mess. Main lines, accumulators, cylinders, pistons involved into acting on the diving planes but also the rudders torpedo tube outer doors, even the remotelly operated antiaircraft gun turrets, were a step too far in tech. They proved too complex and delicate while being outside the pressure hull. Not only they could not be repairs, but their location made them more vulnerable. They could eb the subject of saltwater leakage and corrosion also, leading to many crippling failures.
The Snorkel was not operating properly. In moderate seas, the snorkel mast dunked and thus, closed the air intake and exhaust ports, causing frequent “shutdowns” in diesel propulsion. Salt water also poured into the bilges and and noisy pumps were needed to avoid flooding, making the su easy to detect with a sonar. When closed, the diesels sucked air from inside the boat while exhaust gas backed up also inside. Snorkeling therefore in the north atlantic was quite a painful experience, usable in special occasions only.
it took years to the US Navy to integrate the process into at frist modernizaing their large numbers of Gato/Tench/Balao, making the famous “fleet snorkels” of the 1950s. New conventional attack submarines were developed in small series, prototypes, in order to test the water of the concepts seen in the Type XII. The USSR did not have the same issues with the design and right away designed their own ass-produced version of the Type XXI, the “Whiskey” class attack submarine, which necame a major concern for NATO in the 1950-60s. The developmet of a “true submarine” was eventually seen in the US as getting rid of batteries and snorkels, leading to the design of the USS Nautilus in 1952.
French Evaluation
Roland Morillot at sea c1950
The French obtained U-2518. It became the “Roland Morillot”, and retained not only for tests, but as an active unit. Indeed, unlike its allies, French submarine production stopped completely in WW2, while losses were still important. In 1945, the whole prewar fleet was considered obsolete, and any new sub, especially one with such advanced caracteristics, was desirable in the French post-war fleet.
Therefore, the ex-Type XXI was used for active service, and even operated during the Suez Crisis in 1956, staying in commission as Q426 until 1967, scrapped in 1969. This was a unique case among allies, but it left plenty of time for the crews to appreciate the design and fully evaluate it in a variety of environments and operational conditions, quite an insight about the type. Its influence on French conversions and newly built vessels was very impactful (see later, legacy).
The Roland Morillot started service on 13 February 1946, apparently it was not in French hands since August 1945*, so six months were spent evaluating the type as it is sometimes stated. Nevertheless in 1946, the French were writing an extensive report and eventually converting the boat, after repairs, for French use (notably all german-written indication onboard), and some compatibility with torpedoes (although there were enough German model stocks left in France in 1945, at Lorient notably) and general practice.
For uboat.net however, U-2518 (commissioned 4 Nov 1944 under command of Oblt. Friedrich Weidner, Kptlt. Friedrich Weidner, operaring with the 31. Flottille (training) and 11. Flottille (active), having no kills, and surrendering on 9 May 1945 at Horten, Norway, was transferred to Oslo 18 May, then Lisahally, Northern Ireland on 7 June, but apparently only transferred to France on 14 Feb, 1946. So she was “Frenchified” later; This is confirmed by another French source stating she was integrated gradually from her arrival in Cherbourg on 13 Feb. 1946, and officially leased for two years by the RN, towed to Cherbourg.
It’s only on 20 August 1946, after repairs and overhaul that she started her first sea sortie and later joined the Mediterranean fleet. In 1947, she could have been scrapped, all evaluations done, but it was decided to modifiy her for active service: In 1947 notably she had a major overhaul, her FLAK 37 A.A. guns were removed, some periscopes put to French standards as her armament, staying compatible in the long run. This was all to provide her a long active service as seen above. She later received the code S-12 and on november 11, 1947 experienced a diving incident, waterway by snorkel, being repaired later in Brest. On January 1948 she made a Crossing Toulon-Casabianca entirely underwater, and in April 1, 1948, the leasing expired and she was definitively ceded to the French Navy.
Roland Morillot, ex-U-2518, with its plastic rebuilt fin, was disarmed in 1967.
She would have her FUMG radar dismounted followed in November 1948 by her major overhaul in Brest in which her turrets were removed and the entire kiosk/fin streamlined and rebuilt. She started her post-overhaul sea trials in early 1949 and by April 7, 1949 was back in the Med Fleet, Toulon. She was only officially named Roland Morillot by February 14, 1951, participating in March/April 1954 NATO exercize “Medflex Able”, the only ex-Type XXI ever seen in this. In 1955 her kiosk was modified again, with a rear and top addition in platic to improve further her streamling, and this was her last major modification in her career.
French evaluations in 1946-48 noted her surface speed was 13,2 kts, underwater speed 16 kts, less than her on-paper performances, and she could cover 5,100 nautical miles at 15,6 kts, which they found the most impressive, 15,500 nautical miles at 10 kts and 280 nm at 6 kts underwater. For them, the AA armament in a postwar context made no sense, and it was planned to remove it soon. They also evaluated her buoyancy to 227,8 tonnes and her coeficient for the latter to be 12,6%. The snorkel’s advantages were recoignised, but also its drawbacks, and it was judged more suited for the calmer Mediterranean, and even so, problems were soon found.
The electrical power however was considered a real bonus, to be applied on the reconstruction of the La Creole class, and applied to the postwar Narval class, almost a carbon-copy of the type. The French discarded the AIP system as far-fetched for the tech of the time, and in fact no serious attempt has been made to design one before the famous Australian Barracuda shortfin order in the 2000s, by Naval Group, altough the Scorpene class (all exported) was in some cases to be equiped with the MESMA AIP system, later adopted for the Spanish version.
Soviet Evaluation
Four Type XXI boats were allocated to the USSR by the Potsdam Agreement, in accordance to their contribution: U-2529, U-3035, U-3041, and U-3515. Upon arrival, they were all commissioned directly into the Soviet Navy as B-27, B-28, B-29, and B-30.
Western intelligence believed more has been catpured in fact, notably those from Dantzig. A U.S. Joint Intelligence Committee review for the Joint Chiefs of Staff in January 1948 estimated no less than fifteen Type XXIs were operational in Soviet hands, and they would simply copy it, having six more within 2 months and another 39 within a year, just using existing German prefabricated sections from captured factories assigned to the Danzig yard, all in the Soviet area of occupation.
U-3538 to U-3557 (renamed TS-5 to TS-19 and TS-32 to TS-38) remained incomplete in Danzig, scrapped or sunk in 1947 and the four boats allocated wree exnensively tested and trialled until 1955. They were then eventually scuttled or expended as targets in 1958-1973. The although knowledge about Soviet evaluation of the time remains largely classified to this day, the type formed the basis for several successive Soviet design projects, namely Pro’yekt 611, 613, 614, 633, and 644 (NATO Zulu, Whiskey, Romeo). They came with most of the original boats features, snorkel and electrical power, better optics, better sonar (although the Soviets were long lacking in this field), and early acoustic torpedoes. They got rid of the embedded AA armament, but strangely for the first batches reintroduced the deck gun.
Postwar legacy
The ex-Type XXI Wilhelm Bauer rebuilt in service with the Bundesmarine in the 1960s. Note the kiosk’s missing AA guns, replaced by a glassed section, heavy weather helm.
It would be an understatement as how important the Type XXI design was. Even without the initially projected AIP turbine, the whole package it represented was enough to have all submarine-building nations reset their software. The war prizes as we saw her a considerable influence on many WW2 boats conversion as with new designs, many still in service at the end of the cold war in 1990. It is a paradox for a boat which a so insignificant tally compared to previous Types in WW2. Despite the massive resources poured in it, it came far too late to change anything, but it’s the groundbreaking tech behind that really constitutes its legacy.
Wilhelm Bauer as preserved in Bremershaven
In Germany itself, the Bundesmarine resurrected in 1957, the sunken U-2540, scuttled in 1945. She was was raised and refitted as the research vessel Wilhelm Bauer. It was also operated by both military and civilian crews, for research purposes until 1982. Its role was also to help creating the first postwar class of German subamrine (albeit a mediocre one), the Hai class and Type 201 although they arguably were more derived from the Type XVIII elektroboote than the Type XXI. In 1984, Wilhelm Bauer was made available for display to the public, at the Deutsches Schiffahrtsmuseum or German Maritime Museum in Bremerhaven, Germany. It is now in permanent display as a museum ship.
The Type XXI was directly the basis for the development of the Project 613, NATO “Whiskey” class, and thus, inspired the Zulu and Quebeck classes attack submarines as well. The Romeo was however a brand new generation, and the Foxtrot, the last “classic” conventional type, arguably derived from the Type XII after a long lineage. The base recipe was still there, only improved. It could be argued also that the 1970s Ming class, based on Soviet blueprints (Romeo class), also had still some Type XXI DNA in them.
In the US, the first impact was on the reconverstion of most still commissioned WW2 Gato/Tench/Balo in post-war years, starting with the long GUPPY program (Greater Underwater Propulsion Program), in what became the “fleet snorkels”, allowing them to serve for another 20 years, or even more in many NATO fleets as well. The measures taken were essentially all inspired by what the Germans did on the Type XXI, consisting in improving the electrical power massively, reworked the bow, the fin, and fit a better sonar and navigation radars, among others. Alongside this overhaul, the semi-experimental Barracuda, Tang and Darter Classes were all derived from these conversions in the 1950s.
In Great Britain, the impact of the Type XXI design on postwar conversions, which mirrored the GUPPY program, concerned the Streamlined and converted T class subs. This also concerned the “A” class designed for the Pacific, most of which already were completed too late so see action in WW2. They were later completely modernized and renamed the “Acheron class”. Another round of remaining conversion in 1955 gave an additional twenty years of service. The first true “new built”, the Porpoise class patrol submarines (1956) were in straight line with these conversions inspired by the Type XXI, as the 1959 Oberons.
France also had it’s “GUPPY” with the prewar built, suspended, then modernized and completed La Creole class. However only two, Artemis and Andromede, had the full rebuilt, allowing them to serve until 1961-67. The Narval class (1954) was very closely based on the Type XXI Roland Morillot. The next Arethuse and Daphne (1957, 1959) were more coastal in nature, but draw on this basic design.
Sources & more:
Books
Blair, Clay (2000). Hitler’s U-boat War: The Hunters 1939-1942. London: Cassel & Co.
Breyer, Siegfried (1999). German U-Boat Type XXI.
Fitzsimons, Bernard, general editor. The Encyclopedia of 20th Century Weapons and Warfare, Volume 24
Gröner, Erich; Jung, Dieter; Maass, Martin (1991). U-boats and mine warfare vessels. German Warships 1815–1945.
Kohl, Fritz; Eberhard Rossler (1991). The Type XXI U-boat. Conway Maritime.
Links
U-2540 cutaway model
Detailed construction on uboatarchive.net
Detailed blueprints reconstructed by the Bundesmarine
ipmsstockholm.org
u-boot-wilhelm-bauer.de
Video T.Lyon “Type XXI, the true story”, Royal Institution of Naval Architects
On uboataces.com
On www.uboat.net
Postwar British evaluation of the Type XXI
On hisutton.com
On uboat.net
On weaponsandwarfare.com
On sudden-strike-maps.de
Type XXX on lexikon-der-wehrmacht.de
hubertcance.com: About the Type XXXI
weaponsandwarfare.com about the Type XXI tech
wikipedia.org
On the Roland Morillot
Same, late service and modifications
Some hardly known aspects of the GHG, the U-boat’s group listening apparatus
Marcus O. Jones, USN academy prof. “INNOVATION FOR ITS OWN SAKE”
On warriormaven.com – The Type 21 fail
Many cc photos of the Wilhelm Bauer
Model Kits
On modelingmadness.com
Type-XXI U Boat Anatomy Ship, Anatomy of the Ship Series
1/700 Skywave
3D Renditions
In world of warships
Gallery
U-BoatsXXI-prows-1945
TypeXXI U-3008 (British war prize)
Typexxi-base-diagram
U-3016 Type XXI January 1945 AGW
U-2511 Bergen
U-3003 row
German submarine U 3008
German Sub U-3008 recommission in US service for test.
U-2540 Wilhelm Bauer Type XXI berthed
Side launch of U-3001
U3505 in drydock, photo taken in in 1946
U3060 in assembly, showing the separate modules
Various captured Type XXI onning towers, dhowing various colors and patterns. The middle one seems to have been entirely painted white or yellow.
Early Type XXI in sea trials off Norway, fall 1944. Note the fair grey livery and apparently darker wornout paint of the conning tower.
TypeXXI engine room
Siemens type 2 GU-365-30 electric unit
Various CT configuratios, notably portholes designs, and masts/periscopic depth
Onboard the W. Bauer: Valves for the compressed air regulation manifolds.
View of the Torpedo Room. The four upper tubes;
Single tube interior
Flooding Valve Manifold
Stern room
Central.
Kitchen (Galley)
Crew’s bunks, there were three on each side, superposed.
The officer’s mess
Depth Gauge and Depth Pad Control
Internals of the Type XXI, BP
snorkel scheme
Sections designs
Sections designs
Conning Tower design
Sections designs
pressure hull design
Aft tail of the Type XXI
Yard’s differences between Vonning Towers
U2518 in drydock, inspected by the allies
U-2505 and other subs captured in May 1945.
Design of the Schnorchel
Design of the Schnorchel with an anti-magnetic? or anechoic? paste
Major sections being assembled
Main command center design, with the radio and sonar rooms.
The F-Boats were built from 1915 and until 1918, to an extent of 75 boats. They were alight wooden-hulled designisable for harbour duties and deployed from specially modified depot ships, the converted ex-pre-dreadnoughts SMS Wittelsbach, Schwaben, Preussen, and Lothringen. When deployed they acted as advanced bases and main defensive platforms as well. Of these 75 boats completed, only one was lost by a mine explosion. After the war they served for harbour and riverine duties under the Reichsmarine, Police and Riverine patrol. 12 were also sold to Belgium, still around in 1940.
R 1 class (1929)
The first group R1 to R16 dated back from 1929. These were small vessels of 26 meters, 60 tonnes with a composite hull, capable of 17 knots. They were still partly inspired by the WWI “F-Boote”. The hull was stepped, with an embeddeded main deck, more typical of service boats than classic warships. The superstructure however was fully enclosed. Armament was reinforced during the war, as by 1943 R1 had four 4 single additional 20mm/65 C/38, and a DCR (Depth Charge Rack) plus ten mines, as the folling boats of the R2 serie, including R8.
The Anglo-German Treaty of 1935 however de facto overruled all remaining limitations officially, and gave the Kriegsmarine some leeway. It enabled the capacity to produce “Washington” cruisers (10,000 tons, eight 8-in guns), but not before 1943. This Agreement was signed on 18 June 1935 and essentially gave the Kriegsmarine 35% of the Royal Navy tonnage.
In June, Joachim von Ribbentrop went to London for the talks, held at the British Admiralty office, with Foreign Secretary Sir John Simon for the British delegation. After some arms twisting on Ribbentrop’s side, it was agreed that Germany would build up their tonnage levels to what Great Britain’s tonnage levels were in the various warship categories. The next weeks were used to fix technical issues.
The three completed ships had the same battery of eight 20.3 cm SK C/34 guns, in four twin turrets, two superfiring pairs fore and aft.
-They had eight 2 cm (0.79 in) Rheinmetall Flak 38 guns. Magazine-fed, they were automatic weapon in part inspired by the Swoss Oerlikon. They fired at up to 500 rounds per minute. They were fed by 40 magazines for a grand total of 16,000 rounds aboard, and some were tracers.
While off the Norwegian coast, Hipper was ordered to locate the destroyer Bernd von Arnim, which had disappeared from view in the mist. One was spotted by the British destroyer HMS Glowworm and duelled, captain Bernd von Arnim requested assistance from Admiral Hipper. When she arrived, Glowworm misidentified her as firendly, which was fatal, as the cruiser left her little chance to escape, opening a withering fire. Glowworm attempted to flee but was not fast enough to dodge more hits, but managed to evade Hipper’s torpedoes, while returning a hit on Hipper’s starboard bow. One hit on the destroyer jammed her rudder and put her in a collision course with Hipper…
U-459 (1941-43)
By that time, RMS Preussen (laid down 1902) approached its replacement date in 1922. The earliest design studies started in 1920, and the admiralty worked on two simple options: Either the new Reichsmarine was to build a heavily armored, but slow and and small warship related to Scandinavian coastal battleships like the Sverige class (Gustav V was in completion at that time, and around 7,000 tonnes) or a large and fast but lightly protected ship related to a cruiser. The first studies on the first option started in 1923 under Admiral Paul Behncke. But by 1924, the German economy virtually collapsed, and all work was halted. Admiral Hans Zenker then took command of Reichsmarine, and immediately pressed on to resume design work. By 1925 at last the first three proposals were drafted, added to the 1923 studies, for five different design philosophies.
RMS (‘ReichsMarine Schiff’) Admiral Scheer was ordered from Reichsmarinewerft shipyard, Wilhelmshaven. The bill ordering her was delayed for obe year, and budget for Panzerschiff B “Ersatz Lothringen” only secured by poltical absention. On launching, she was christened by Marianne Besserer, daughter of the namesake Admiral Reinhard Scheer and completed by 12 November 1934, commissioned the same day. The political context had changed radically by then. Her first command was Kapitän zur See Wilhelm Marschall. She spent December 1934 in sea trials and training and in 1935, as the navy was to be renamed Kriegsmarine, a catapult and landing sail system as fitted. Contrary to her earlier sister ship she was not given He-60 floatplanes but Arado models instead, better fitted to operate in heavy seas. Until 26 July 1937 her captain was Leopold Bürkner, future head of foreign intelligence. In October 1935, she started her first long range cruise, stopping at Madeira and other ports and back to Kiel in November. She then departed for a summer cruise between the English Channel and the Irish Sea, and stopped in Stockholm when back.
Admiral Graf Spee, perhaps the most famous of the three, but also with the shortest career, was ordered as “Ersatz Braunschweig”, replacing Braunschweig and christened by the daughter of Admiral Maximilian von Spee, completed on 6 January 1936 and commissioned the same day. She spend until early April in extensive sea trials and training, under command of Kapitän zur See (KzS) Conrad Patzig (photo), replaced in 1937 by Walter Warzecha. Officially joining the fleet she became the flagship of the German Navy and during the summer 1936, joined the Atlantic for non-intervention patrols off the Spanish coast, hed mostly by the Republicans. Until May 1937 she made three tours of duty here, and stopped on her way in Great Britain for the Spithead Coronation Review held for King George VI, on 20 May 1937.
One month later on June 6, E-boats of the 9th flotilla left Cherbourg harbour at 5 a.m. on 6 June 1944, spotted the entire invasion fleet and closed in, moving in pair to divert attention and counter fire, laying smoke to cover their approach, and fired their torpedoes at maximum range. They quickly retreated and returned to Cherbourg, not achieving a single kill.
